AvMap EngiBox

View more products from AvMap SKU: UX0EMS10AM

$2,099.00

GST includedShipping Info


Special Order
2-3 Weeks Delivery





EngiBOX is a light and compact engine monitor displaying:

  • Exhaust Gas Temperature (EGT)
  • Revolutions per Minute (RPM)
  • Manifold Pressure (MAP)
  • Oil Pressure
  • Oil Temperature / Air Temperature
  • Cylinder Head Temperature (CHT) / Coolant Temperature (CT)
  • EngiBOX Technical Specifications:

Hardware:
Dimensions: 95 x 95 x 88 mm
Fitting standard 79,5 mm (3-1/8?) panel hole
250 g
Display: 3.5 colour LCD, with anti reflective coat 320 240 pixels, 500 cm/m2
Micro SD slot
Real Time Clock
4 x Thermocouples sensor
2 x PT100 sensor
1 x 4-20 mA pressure sensor
1 x RPM
1 x Serial connection
Manifold pressure sensor
Bluetooth Low Energy
Power Input range: 10-35 VDC
Current consumption @ 12VDC: 150 mA MAX
Operating Temperature range: -20 / +70

Software:
Wizard driven engine initialization
Engine data displayed in two alternative views
Graph page for each engine parameter
Clock page including flight time, total lifetime, time since overhaul
Data registration on internal memory and data export to micro SD or EngiBOX mobile App
Compatible Engines:
2 stroke Air cooled: Rotax 447 UL SCDI, Rotax 503 UL DCDI
2 Stroke Liquid cooled: Rotax 582 UL DCDI, Rotax 618 UL DCDI

Stroke Liquid cooled: Rotax 912 DCDI series, Rotax 912S DCDI series, Rotax 914 DCDI series
